Boron-Doped Single Crystal HPHT Diamond Plates
Single crystal boron-doped HPHT diamond plates for electronic, electrochemical, sensor and advanced research applications.
Available in light-doped, heavy-doped and high-boron grades. Standard material is supplied with low nitrogen content (<10 ppb by EPR) and mechanically polished surfaces with Ra <10 nm.
Material Grades
| Grade | Appearance | Boron Concentration |
|---|---|---|
| Light Doped | Light Blue | 1.07 × 10¹⁷ atoms/cm³ |
| Heavy Doped | Dark Blue | 2.29 × 10¹⁷ atoms/cm³ |
| High-Boron | Deep Blue | Up to approx. 9 × 10¹⁸ atoms/cm³ (≈51 ppm) |
| Custom High-Boron | Deep Blue | Up to approx. 90 ppm |
SIMS test reports can be provided upon request.
Specifications
| Item | Description |
|---|---|
| Material | Single Crystal HPHT Diamond |
| Diamond Type | Boron-Doped Type IIb |
| Nitrogen Content | <10 ppb (EPR) |
| Surface Roughness | Ra <10 nm |
| Orientation | <100>, <111> or custom |
| Shape | Square, Rectangular, Plate or Custom |
| Thickness | Custom |
| Surface Finish | Mechanical Polishing or Custom Finish |
| Processing | Cutting, Lapping, Polishing |
Typical Applications
Boron-doped HPHT diamond is used for conductive and semiconductive diamond research, electrochemical electrodes, sensor development, diamond electronics and advanced material studies.
Research institutes, universities and semiconductor laboratories commonly use this material for prototype development, material characterization and device fabrication.
Custom Manufacturing
Custom options are available for boron concentration, dimensions, thickness, orientation and surface finish.
Additional services may include:
Metallization
Electrode patterning
Laser marking
Special polishing requirements
Ordering Information
For quotation, please provide the required dimensions, thickness, boron concentration, crystal orientation and quantity.
If electrical performance is critical to the application, please specify the target conductivity, resistivity or measurement method during inquiry.
